National Instruments cDAQ-9181 CompactDAQ Chassis
The cDAQ-9181 (Part Numbers: 782052-01 and 781496-01) can be used with the C Series simple input modules that are particularly intended for estimating signals that fluctuate gradually, such as temperature. Due to their moderate rate, it is not suitable for these modules to oblige the AI Sample Clock to work at slower than their most extreme rate. When utilizing such a module in the NI cDAQ-9181 frame, the greatest sample rate can run quicker than the most extreme rate for the module. While working at a rate quicker than these moderate rate modules, the moderate rate module restores a similar point over and over, until another transformation finishes.
On the NI cDAQ-9181 1-Slot Ethernet Chassis, it is possible to utilize Reference Trigger to stop an estimation obtaining. To utilize a reference trigger, determine a cushion of limited size and various pre-trigger (tests that happen before the reference trigger). The quantity of post-trigger (tests that happen after the reference trigger) wanted is the cradle estimate of the quantity of pre-trigger tests.
To create a simple input, embed a simple input C Series module in any opening on the National Instruments NI cDAQ-9181. The age determinations, such as the quantity of channels, channel design, refresh rate, and yield extend, are controlled by the type of C Series module utilized. On a solitary simple yield C Series module, the user can dole out any number of channels to either an equipment planned assignment or a product coordinated (single-point) errand. Nonetheless, the user cannot allot a few channels to an equipment planned errand and different channels (on a similar module) to a product coordinated undertaking.
Additional specification information for the cDAQ-9181 can be found in the manuals and datasheets under the "Manuals & PDFs" tab. The "Drivers & Software" tab has cDAQ-9181 drivers available for free download.
| Model | cDAQ-9181 |
|---|---|
| Manufacturer | National Instruments |
| Part Numbers | 781496-01, 782052-01 |
| Type | CompactDAQ Chassis |
| Slots | 1 |
| Bus Connector | Ethernet |
| Timing Resolution | 12.5 ns |
| Dimensions | 7.64 x 3.49 x 1.32 in. |
| Weight | 16.6 oz. |
| Warranty | 2-3 Year Warranty |
| cDAQ-9181 Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
Associated part numbers for cDAQ-9181:
150227A-02L, 150227B-02L, 150227B-12L, 150227C-02L, 150227C-12L, 150227D-02L, 150227D-12L, 150227E-02L, 150227E-12L, 150227F-02L, 781496-01, 782052-01
National Instruments cDAQ-9181 Frequently Asked Questions
Question: What is the difference between the two part numbers for the cDAQ-9181 NI?
Answer: The cDAQ-9181 NI has one version that is conformal coated (Part Number: 781496-01) and another version that is not conformal coated (Part Number: 782052-01).
Question: Why is MAX/Windows unable to detect my NI cDAQ-9181 that I’ve connected via Ethernet?
Answer: If MAX is not detecting your NI cDAQ-9181, then download and install DAQmx 18.0.0.
Question: Why is my cDAQ-9181 CompactDAQ Chassis grayed out after rebooting my computer?
Answer: If your cDAQ-9181 CompactDAQ Chassis is grayed out after booting your system, it means that the device is not available. Program a self-test function that is set to occur every time you run the application to ensure that your device shows as available each time.
Question: How can I access the National Instruments NI cDAQ-9181 and reset network settings if I forgot my password?
Answer: When using the National Instruments NI cDAQ-9181, you can change your password by physically accessing the device and pressing the reset button located at the top of the device for over 5 seconds, until the STATUS LED lights up.
Question: How do I find the MAC address of my Ethernet connected NI cDAQ-9181 1-slot Ethernet Chassis?
Answer: You can find the MAC address of your NI cDAQ-9181 1-slot Ethernet Chassis by either opening MAX, selecting Ethernet cDAQ under network devices, and then going into Network Settings to see the MAC address or by looking on the back of the hardware device for the sticker with the MAC address.
Question: What should I do if MAX / Windows cannot detect my cDAQ-9181 or the module I have plugged into it?
Answer: You will need to make sure that your drivers are compatible with the version of LabVIEW you are using. You might need to upgrade to the newest version of LabVIEW, or revert back to a previous version of NI-DAQmx.
cDAQ-9181 PDF Manuals
NI CDAQ 9181 9184 9188 9191 USER MANUAL.PDF
NI CDAQ 9181 ETHERNET CHASSIS QUICK START.PDF
NI CDAQ 9181 NI CDAQ 9184 NI CDAQ 9188 NI CDAQ 9188XT LETTER OF VOLATILITY.PDF
NI CDAQ 9181 SAFETY ENVIRONMENTAL AND REGULATORY INFORMATION.PDF
NI CDAQ 9181 SPECIFICATIONS.PDF
CDAQ 9181 9184 9188 9191 FIRMWARE FOSS NOTICES LOCATIONS NOTE TO USERS.PDF
CDAQ 9181 CDAQ 9184 CDAQ 9188 CDAQ 9188XT LETTER OF VOLATILITY.PDF
CDAQ CHASSIS AND CONTROLLERS CALIBRATION PROCEDURE.PDF
Driver Downloads for cDAQ-9181
OS Compatibility:
Win XP 32-bit, Win 7 32-bit, Win 10 32-bit
