National Instruments PXIe-8106 PXI Controller
The PXIe-8106 (Part Numbers: 779920-00, 779920-01, 779921-00, and 779921-01) is a Dual-Core Processor, Embedded Controller for PXI and CompactPCI frameworks. It is utilized for measured instrumentation and DAQ applications. The NI PXIe-8106 incorporates 10/100/1000BASE-TX (Gigabit) Ethernet and four Hi-Speed USB ports, as well as an integrated hard drive, a serial port, and other types of peripheral I/O.
The modularity of PXI and open development environment of LabVIEW make it simple to integrate an assortment of I/O inside the user’s application. Users can make a custom continuous embedded arrangement utilizing the PXIe-8106 with any number and mix of PXI/CompactPCI plug-in modules. With built-in LabVIEW libraries, the user can make applications with data acquisition, dynamic signal acquisition, motion control, image acquisition, reconfigurable I/O, and instrumentation. In addition, the user can communicate with CAN gadgets, GPIB, Ethernet, or serial protocols, and utilize NI-VISA software to incorporate outsider PXI/CompactPCI modules into an application.
The NI PXIe 8106 will enable users to make reliable stand-alone systems. To guarantee dependable activity, embedded LabVIEW Real-Time applications keep on running regardless of whether the host PC is interrupted or rebooted. Since the National Instruments PXIe-8106 Embedded Controller keeps running in a different chassis with a dedicated power supply, the user can close the host PC without disturbing the continuous program. For remaining single activity, users can add code in the framework with the goal that it begins consequently when the framework boots, requiring no human association. It is also possible to utilize the LabVIEW Professional Development System and LabVIEW Real-Time Module to arrange the LabVIEW application and download it to the NI PXIe-8106 Controller.
| Model | PXIe-8106 |
|---|---|
| Part Numbers | 779920-00, 779920-01, 779921-00, 779921-01 |
| Manufacturer | National Instruments |
| Type | PXI Controller |
| Processor | 2.16 GHz Intel Core 2 Duo Processor T7400 |
| Standard RAM | 512 MB |
| Maximum RAM | 2 GB |
| Board Dimensions | 4-slot 3U PXI module |
| Weight | 2.1 lb. |
| Warranty | 2-3 Year Warranty |
| PXIe-8106 Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
Associated part numbers for the PXIe-8106:
196874G-723, 196874G-812, 196874G-823, 196874H-012, 196874H-712, 196874H-812, 779920-00, 779920-01, 779920-02, 779920-04, 779921-00, 779921-01, 779921-02, 779921-04, 781675-01, 1.96874E-07, 1.96874E-18, 196874A-012, 196874A-023, 196874A-712, 196874A-723, 196874A-812, 196874A-823, 196874B-012, 196874B-023, 196874B-712, 196874B-723, 196874B-812, 196874B-823, 196874C-012, 196874C-023, 196874C-712, 196874C-723, 196874C-812, 196874C-823, 196874D-012, 196874D-023, 196874D-712, 196874D-723, 196874D-812, 196874D-823, 196874E-712, 196874E-723, 196874E-912, 196874E-923, 196874F-012, 196874F-023, 196874F-712, 196874F-723, 196874F-812, 196874F-823, 196874G-012, 196874G-023, 196874G-712
National Instruments PXIe-8106 Frequently Asked Questions
Question: What are the recommended memory upgrade options for the PXIe-8106?
Answer: The PXIe-8106 has a 512 MB RAM option (part number: 779301-512), a 1 GB RAM option (Part number: 779302-1024), and a 2 GB RAM option (part number: 780031-2048).
Question: Why are there several part numbers for the NI PXIe-8106?
Answer: The NI PXIe-8106 has a base model and an extended temperature and 24/7 operation model. Both models also have different installed OS to choose from. Part number 779920-01 is the base model with Windows XP Professional (English) installed, while part number 779921-01 is the extended temperature and 24/7 operation model with Windows XP Professional (English) installed. Part number 779920-00 is the base model with Localized Windows XP or another OS, whereas part number 779921-00 is the extended temperature and 24/7 operation model with Localized Windows XP or another OS installed.
Question: What are the PXI Express Link Configuration options for the PXIe-8106?
Answer: The PXI Express Link Configurations for the PXIe-8106 are 3 x4 links and 1 x1 link for 4-link configuration and 2 x4 links for 2-link configuration.
Question: What are the slot requirements for the NI PXIe-8106?
Answer: The slot requirements for the NI PXIe-8106 are 1 system slot and 3 controller expansion slots.
PXIe-8106 PDF Manuals
ARCHIVED NI PXIE 8106 INSTALLATION GUIDE.PDF
ARCHIVED NI PXIE 8106 USER MANUAL AND SPECIFICATIONS.PDF
PHASE MATRIX PXI 1410 QUICK START GUIDE.PDF
PHASE MATRIX PXI 1420 QUICK START GUIDE.PDF
PHASE MATRIX PXI 1450B QUICK START GUIDE.PDF
PXI EXPRESS EMBEDDED CONTROLLERS PRODUCT FLYER.PDF
