Keysight N2100A-H10, 3-slot, Optical Bandwidth PXI Digital Communication Analyzer
Need an Official Quote?
Keysight N2100A-H10 PXI Digital Communication Analyzer
The Keysight N2100A-H10 is an obsolete Digital Communication Analyzer (DCA) that is mainly utilized for production ATE applications. This PXI Digital Communication Analyzer was previously PXIT Inc. product PX2000-333 and may still be referred to as such in documentation. The N2100A-H10 is a 3-slot PXI card with an eye diagram, jitter assessment, and mask assessment in one device. The N2100A-H10 has a wideband optical input, which is great for electro-optical transceivers, TOSAs, and VSR parallel optics modules. There is also an electrical input on this analyzer, which is well-suited for ROSAs and high-speed serial data interconnects. With this analyzer, integral clock recovery is possible for measurements to 3.0 Gb/s maximum. The user should keep in mind that this model is not suggested for operation at 3.125 Gb/s with a PRBS-7 pattern.
Several of the measurements that can be made with the Keysight N2100A-H10 Digital Communication Analyzer include eye width, random jitter, P-P and RMS noise measurements, eye opening, mask comparison and margin, and a variety of others. This Keysight DCA can be controlled via the Control Panel. The top row of buttons can be utilized to configure the module, I/O, and link to the module. Additionally, the operation mode can be controlled with the list box in the top left corner. There are five measurement modes which can be accessed from the Control Panel. More information about the measurement modes and setting the parameters for the DCA can be found in the user manual.
Model | N2100A-H10 |
---|---|
Manufacturer | Keysight Agilent HP |
Type | PXI Digital Communication Analyzer |
Unfiltered Optical BW | 7 GHz |
Electrical BW Input | 0.1 - 7000 MHz (characteristic) |
Maximum Input Range (p-p) | 1500 mV |
Optical Responsivity | 780-1600 nm |
Slot Requirements | 3 |
External Reference Clock Input | SMA |
Warranty | 2-3 Year Warranty |
N2100A-H10 Manual | User Manual and Maintenance Manual Available for Download |
Price | Contact a sales representative for a quote. |
Keysight N2100A-H10 Frequently Asked Questions
Question: What is the optical bandwidth coverage for the N2100A-H10?
Answer: The optical bandwidth coverage for the N2100A-H10 is 780nm to 1620nm.
Question: What does the calibration feature on the Keysight N2100A-H10 help with?
Answer: The calibration feature on the Keysight N2100A-H10 helps compensate for dark current drift caused by temperature or time.
Question: Which types of software can be used with the N2100A-H10 DCA?
Answer: The N2100A-H10 DCA can be used with C++, National Instruments Test Stand, Microsoft Visual Basic, and National Instruments LabVIEW and LabWindows.
