National Instruments AT-MIO-16F-5 Multifunction I/O Board
The AT-MIO-16F-5 (Part Number: 180985-01) is a multifunction digital, analog, and timing input/output board designed and manufactured by National Instruments. The NI AT-MIO-16F-5 is created for use with the IBM PC AT and compatibles, as well as EISA PCs. This Multifunction I/O Board is an advanced version of the AT-MIO-16 with added features, such as higher throughput, more gains, software pretriggering, software configurable analog input, and more.
This board features 16 single-ended terminals. The channels of the AT-MIO-16F-5 can also be programmed to be used as 8 differential channels. The number of channels can be increased by using the AT-MIO-16F-5 with the AMUX-64T multiplexer board. With the AMUX-64T multiplexer board, the input channels for the AT-MIO-16F-5 board can be increased to 64 single-ended and 32 differential inputs. The input channels can be further increased to 256 single-ended channels by cascading 4 AMUX-64T multiplexer boards.
This Multifunction I/O Board features a 256-word analog to digital buffer, sampling analog to digital converter (ADC) providing a data transfer rate of nearly 200 ksamples/sec, and a variable gain setting ranging from 0.5 to 100. Additionally, the AT-MIO-16F-5 board contains 12-bit, double-buffered digital to analog converters, which provide voltage output in unipolar and bipolar format, auto-calibration circuitry, 8 digital input/output lines, 4 triggers, and an RTSI bus interface.
The NI AT-MIO-16F-5 board is used for process control, level monitoring, electronic testing, transient analysis, data logging, chromatography, signal analysis, and a variety of other functions. The TTL compatible digital input lines of the board support switching control of relays, process control, and inter-machine communication. The onboard 16-bit timers are used for clock generation, control of laboratory equipment and measurement of events, frequency, and pulse-width, making the automatic control and monitoring of laboratory processes possible.
Model | AT-MIO-16F-5 |
---|---|
Manufacturer | National Instruments |
Part Numbers | 180985-01 |
Series | AT Series |
Type | Multifunction I/O Board |
Analog Input Channels | 16 single-ended, 8 differential |
Analog Output Channels | 2 |
Type of DAC | 12-bit, multiplying |
Timing I/O Channels | 3 counter/timers |
I/O Connector | 50-pin, male, ribbon cable header |
Dimensions | 13.3 x 4.5 in. |
Warranty | 2-3 Year Warranty |
AT-MIO-16F-5 Manual | User Manual and Maintenance Manual Available for Download |
Price | Contact a sales representative for a quote. |
Associated part numbers for the AT-MIO-16F-5:
180985H-01, 180985-01, 776441-01, 180985-01G
