cRIO-PB-S
cRIO-PB-S alt2
cRIO-PB-S New small
cRIO-PB-S Refurb small

Pictures shown are a representation. Actual item may vary if no part number is provided on quote request.

Same Day Calibration Available

2-3 Year Warranty Included

Free Ground Shipping

Or speak to a sales representative for additional information:

cRIO-PB-S Request for Availability

cRIO-PB-S, Slave, C Series PROFIBUS Interface Module

Rated 4.7/5 | 16 ratings

Please fill out the form below to send in your quote request and a representative will contact you with a formal quote. View blog post on Model Name vs. Part Numbers

+Add more parts

Prefer to send a text message?

Text your name, e-mail, and parts to quote to:   1-919-809-5227

National Instruments cRIO-PB-S C Series PROFIBUS Interface Module

The cRIO-PB-S is a CompactRIO PROFIBUS Slave Interface Module. The NI cRIO-PB-S module is a product made by National Instruments. The cRIO-PB-S is built with the part number 781351-01. The NI cRIO-PB-S is designed to enable CompactRIO systems to communicate with typical PROFIBUS DP Networks. The cRIO-PB-S PROFIBUS Interface Module is made to support maximum PROFIBUS baud rates of 12000 kbits/s.

The NI cRIO-PB-S C Series PROFIBUS Interface Module is compatible with only CompactRIO systems. The National Instruments cRIO-PB-S module accumulates the PROFIBUS DP Master configuration in the integrated flash memory. The NI cRIO-PB-S PROFIBUS Interface Module connects NI programmable automation controllers (PACs) to the PROFIBUS industrial networks. In the NI cRIO-PB-S module, the network baud rate can be detected automatically and supported by cyclic input and output data up to 240 Bytes each

The National Instruments cRIO-PB-S C Series PROFIBUS Interface Module comes with an easy-to-use FPGA driver interface and a detailed sample code to be integrated directly into the user application. The cRIO-PB-S module is supported only in CompactRIO reconfigurable chassis like NI Single-Board RIO devices. PROFIBUS data rates ranges from 9600 bit/s to 12000 kbits/s. The NI cRIO-PB-S PROFIBUS Interface Module has a process image data size of 8 kbyte. The cRIO-PB-S module contains a PROFIBUS Interface with one 9-pin D-SUB port and an isolated RS485 interface. This C Series Module also has a PROFIBUS isolation voltage of 500 VDC and 2.5 W power requirements in active mode for both transmitting and receiving.

ModelcRIO-PB-S
ManufacturerKUNBUS/National Instruments
Part Number781351-01
SeriesC Series
TypePROFIBUS Interface Module
PROFIBUS Network RoleSlave
Maximum Baud Rate12000 kbits/s
Power Requirements2.5 W Active Mode (Transmitting and Receiving)
Warranty2-3 Year Warranty
cRIO-PB-S ManualUser Manual and Maintenance Manual Available for Download
PriceContact a sales representative for a quote.

Associated part numbers for cRIO-PB-S:
