cFP-2110 In Stock | Ships Today
cFP-2110, 2 Serial Port, Compact FieldPoint Controller
Need an Official Quote?
National Instruments cFP-2110 Compact FieldPoint LabVIEW Real-Time/Ethernet Network Controller
The cFP-2110 (Part number: 777317-2110) is a high-performance Compact FieldPoint Controller from National Instruments. This model can be utilized for embedded and distributed I/O applications. The user can control it without having any prior knowledge of programming. Users can carry out real-time measurements, analysis, and simulation. The NI cFP-2110 FieldPoint Controller enables the user to create user-defined applications, such as data logging, I/O, PIDs, signal processing, and analysis algorithms. There are various applications for control engineers in industrial environments. These applications include PID control loops, actuate valves, and motors.
The NI cFP-2110 FieldPoint Controller also offers peer to peer communication capabilities for cFP-21xx Intelligent FieldPoint Controllers and Ethernet-based devices. The instrument offers various interfaces and control features on the front panel, which includes Ethernet and RS-232 communication ports, LED indicators, DIP switches, a reset switch, and power connector. The backplane of the instrument offers a mounting capability for a standard 19-inch rack. There are numerous controlling techniques available with or without a host PC. The NI cFP-2110 FieldPoint Controller also comes with a network watchdog feature to protect the system against network connection failures, cables, or the host computer. This feature is disabled by default.
The National Instruments cFP-2110 FieldPoint LabVIEW Real-Time/Ethernet Network Controller complies to IEEE802.3 specifications. The instrument incorporates 10BaseT and 100BaseTX Ethernet and offers the communication rates of 10 and 100 Mbps. These rates are auto-negotiable. This model also includes 64 MB of nonvolatile storage memory and 128 MB of DRAM. The lifetime of the memory is 300,000 times per sector.
| Model | cFP-2110 (777317-2110) |
|---|---|
| Manufacturer | National Instruments |
| Series | cFP20xx |
| Type | Compact FieldPoint LabVIEW Real-Time Controller |
| Ethernet Ports | 1 |
| SDRAM Memory | 128 MB |
| Internal Nonvolatile Storage | 64 MB |
| Warranty | 2-3 Year Warranty |
| cFP-2110 Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
Associated part numbers for the cFP-2110:
1.88543E-07, 188543D-12, 188543F-12, 188543G-12, 1901.87, 190187B-02, 190187D-02, 190187F-02, 190187G-02, 190187H-02, 190187J-02, 190187K-02, 190187L-02, 190187M-02, 190187N-02, 190187P-02, 190187R-02, 190187T-02, 190187U-02, 195854A-02, 195854B-02, 195854C-02, 777317-2110
National Instruments cFP-2110 Frequently Asked Questions
Question: How much storage does the cFP-2110 provide?
Answer: The cFP-2110 has 64 MB of nonvolatile storage and 128 MG of SDRAM.
Question: What type of interface is used with the NI cFP-2110?
Answer: The NI cFP-2110 uses an Ethernet interface for PC-based I/O.
Question: Is the cFP-2110 considered an industrial grade product?
Answer: Yes, the cFP-2110 is industrial-grade with 50 g shock, 5 g vibration, and -40 °C to 70 °C operating range.
cFP-2110 PDF Manuals
CFP 21XX AND CFP BP X USER MANUAL.PDF
CFP 21XX QUICK START GUIDE.PDF
FIELDPOINT SAFETY AND RADIO FREQUENCY INTERFERENCE READ ME FIRST.PDF
USING FIELDPOINT AND COMPACT FIELDPOINT SAFELY IN HAZARDOUS LOCATIONS 5BNOTE TO USERS5D.PDF
Driver Downloads for cFP-2110
OS Compatibility:
Win XP 32-bit, Win 7 32-bit, Win 10 32-bit
