PXI-6528 In Stock | Ships Today
PXI-6528, 24 Digital Input / Output Channels, PXI Digital I/O Module
Need an Official Quote?
National Instruments PXI-6528 PXI Digital I/O Module
The NI PXI-6528 (Part number: 778543-01) is a PXI Digital I/O Module featured with 48 channels in all: 24 optically isolated digital Inputs, and 24 solid-state relay outputs, with Channel-Channel Isolation. This model is a cost-efficient, industrial, parallel digital I/O module with included programmable power-up states. This module comes with a sturdy configuration and can provide as many as 24 isolated input and output channels. It also features change detection, real-time system integration (RTSI), and digital filtering. This model is ideal for high voltage switching and isolation in both laboratory and industrial environments.
This PXI Digital I/O Module requires no jumper setting for I/O configuration, since it is entirely software configurable. The NI PXI-6528 is completely compliant with the PCI Local Bus and the PXI hardware standards and specifications. It is a smart system capable of automatically allocating all device resources, including the input level and base address.
Like other measurement devices from National Instruments, the PXI-6528 comes with NI-DAQ driver software. This software has a wide-ranging collection of VIs and functions, which the user can initiate from their software such as LabWindows™ or LabVIEW to program all the programmable features of the PXI-6528. The device is equipped with a 100-pin keyed female SCSI connector. It has an input voltage range of -60 VDC to 60 VDC, and a maximum input current of 3.0 mA.
The NI PXI-6528 employs the RTSI bus interface to trigger signals between the NI PXI-6528 and other RTSI-compatible instruments or devices. The change detection feature of the NI PXI-6528 can easily be programmed to initiate an interruption in case a change occurs on any input line. This Digital I/O Module can also monitor changes on either user-defined or all input lines. It generates an interruption whenever an input deviation occurs.
The NI device weighs 4.6 oz, and measures 6.3 x 3.9 in. in physical dimensions. It has a recommended operating temperature range of 0 to 55 °C, and a storage temperature range of –20 to 70 °C. The module has a typical power requirement of 400 mA at +3.3 VDC, and 250 mA at +5 VDC.
| Model | PXI-6528 (778543-01) |
|---|---|
| Manufacturer | National Instruments |
| Type | PXI Digital I/O Module |
| Channels | 24 optically isolated digital input channels and 24 solid-state relay output channels |
| Connector Type | 100-pin keyed female SCSI connector |
| Input Voltage Range | –60 VDC to 60 VDC |
| Input Current | 3.0 mA/channel, max |
| Warranty | Three Year Warranty |
| PXI-6528 Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
Associated part numbers for the PXI-6528:
18815, 188150A-01, 188150B-01, 188150B-02, 188150C-01, 188150D-01, 188150D-02, 188150F-01, 188150F-02, 188150G-01L, 188150G-02L, 188150H-01L, 188150H-02L, 188150J-01L, 188150J-02L, 778543-01, 778543-02
National Instruments PXI-6528 Frequently Asked Questions
Question: How does the PXI 6528 handle high and low voltages?
Answer: The PXI 6528 has optical isolators that separate the high-voltage front end from the low-voltage back end.
Question: Is the NI PXI-6528 suited for aerospace applications?
Answer: The NI PXI-6528 is ideal for aerospace, laboratory research, and biomedical applications.
Question: Is the NI PXI 6528 equipped with jumpers?
Answer: The NI PXI 6528 device is jumper-free and utilizes DAQmx measurement services software to speed up application development.
PXI-6528 PDF Manuals
DAQ GETTING STARTED GUIDE FOR PXI PXI EXPRESS.PDF
DAQ GETTING STARTED READ ME FIRST NI DAQMX AND DAQ DEVICE INSTALLATION GUIDE.PDF
NI 6528 6529 USER GUIDE AND SPECIFICATIONS.PDF
NI 6528 LETTER OF VOLATILITY.PDF
NI 65XX PINOUT LABEL FOR THE SCB 100A NOTE TO USERS.PDF
NI 65XX PINOUT LABELS FOR THE SCB 100 NOTE TO USERS.PDF
STATIC DIO REGISTER LEVEL PROGRAMMER MANUAL FOR 6509 651X 6520 6521 AND 6528 DEVICES.PDF
