777384-02 In Stock | Ships Today
777384-02, 16 Bits, 2 Voltage Outputs, 100 kS/s, PCI-6030E Multifunction DAQ
Need an Official Quote?
National Instruments 777384-02 Multifunction DAQ
The part number 777384-02 from National Instruments is the identifying part number for the PCI-6030E Multifunction DAQ. This module features 16 number of analog input channels that can be configured as single-ended or 8 differential. It has a 16 bit analog to digital convertor. This high resolution ensures precise measurements. It supports a maximum sampling rate of 100 kS/s with a streaming-to-disk rate of 100 kS/s. This module offers a various range of input signals of 20 Volts with a ±10 V bipolar range and no unipolar range. It has an input coupling of DC with a maximum working voltage of ±11 V, ensuring safe and reliable operations. This Multifunction DAQ module is also equipped with overvoltage protection of ±25 V when powered on while ±15 V when powered off.
This module also features a 1024 samples FIFO buffer memory size and with data transfer methods of DMA, interrupts, programmed I/O. It has a scatter gather DMA modes and a configurable memory size of 512 words. This PCI multifunction DAQ module 2 analog output channels with a 16 bit resolution. It supports a maximum update rate of 100 kS/s with a double buffered digital to analog convertor and a 2,048 samples FIFO buffer size. It has an output voltage range of 0 to 10 V with an output coupling of DC and output impedance of 0.1 Ω max, ensuring precise high frequency signal handling.
This module is manufactured to work at power of 1.5 A at +5 VDC with power available of +4.65 to +5.25 VDC, 1 A at the I/O connector. Its physical dimensions are 17.5 cm by 10.6 cm (6.9 by 4.2 in) and weighs 0.8 kg (1.7 lb). It is equipped with a 68-pin male SCSI-II type I/O connector that allows easy integrations into other digital devices.
The 777384-02 module functions at ambient temperature of 0 to 55 degrees Celsius and storage temperature of -20 to 70 degrees Celsius with a relative humidity of 10% to 90%, noncondensing. It does not have ingress protection rating which means that it should be used in environments that are moisture and dust free.
| Part Number | 777384-02 |
| Model Name | PCI-6030E |
| Part Type | Multifunction DAQ |
| Number of Analog Input Channels | 16 single-ended or 8 differential |
| ADC Resolution | 16 bits |
| Maximum Sampling Rate | 100 kS/s |
| Streaming-to-Disk Rate | 100 kS/s |
| FIFO Buffer Size | 512 samples; 1024 samples for DAQCard |
| Number of Analog Output Channels | 2 voltage outputs |
| Maximum Update Rate | 100 kS/s |
