777792-01, Single Port, 12 to 30 VDC, FP-1601 Ethernet Interface for FieldPoint
Need an Official Quote?
National Instruments 777792-01 Ethernet Interface for FieldPoint
National Instruments part number 777792-01 is an identifying part number for the FP-1601, an Ethernet Interface for FieldPoint with a power supply range of 12 to 30 VDC and 1 port. The NI 777792-01 model is designed to link a 10/100 Ethernet network to FieldPoint I/O modules. The total number of FP-1601 modules that can be installed on a network depends on the network topology.
Each 777792-01 Ethernet Interface can connect up to nine FieldPoint I/O modules to a high-speed Ethernet network. The module is equipped with LED indicators that provide status information and DIP switches that perform various functions. A FieldPoint (FP) bank includes one network module along with multiple I/O modules and terminal bases. This Ethernet Interface supports an event-driven protocol, features one port, and achieves a maximum data communication rate of 100 Mb/s with a 10/100 BaseTX network interface. These specifications make this device easy to interface with a PC and straightforward to use.
Additional features include configurable I/O power-up states, a network watchdog timer, automatic self-diagnostics, and more. The 777792-01 model features a 10BaseT and 100BaseTX network interface compatible with IEEE802.3 standards. It supports communication rates of 10 Mbps and 100 Mbps, which are auto negotiated. The maximum cabling distance is 100 meters (328 feet) per segment. The power supply range is 12 to 30 VDC, with a power consumption of 4.5 watts plus 1.1 times the sum of the I/O module consumption. The 777792-01supports a maximum of nine terminal bases per bank.
| Part Number | 777792-01 |
|---|---|
| Model Name | FP-1601 |
| Part Type | Ethernet Interface for FieldPoint |
| Terminal Wiring | 16-26 AWG copper conductor wire with 7 mm (0.275 in) strip length |
| Power Supply Range | 12 to 30 VDC |
| Compatibility | IEEE802.3 |
| Network Interface | 10Base-T and 100Base-TX Ethernet |
| Communication Rates | 10 Mbps, 100 Mbps, auto negotiated |
| Maximum Terminal Bases per Bank | 9 |
| Maximum Cabling Distance | 100 m/segment (328 ft/segment) |
