PXIe-5774
Modular Systems > National Instruments > FlexRIO
| Description: | PXIe-5774, 2-Channel, 12-Bit, PXI FlexRIO Digitizer |
Need an Official Quote?
Or speak to a sales representative for additional information:
Phone:1-800-915-6216
Email:sales@apexwaves.com
National Instruments PXIe-5774 PXI FlexRIO Digitizer
The PXIe-5774 is a PXI FlexRIO Digitizer. Launched by National Instruments, the PXIe-5774 is available in six versions, differentiated by the part numbers 785646-01, 785647-01, 785646-02, 785647-02, 785647-11, and 785647-12. These parts differ in both their analog input bandwidth and their FPGA, with either a Kintex UltraScale KU040 or KU060 FPGA and a bandwidth of either 1.6 GHz and 3 GHz. The NI PXIe-5774 has an analog-to-digital converter featuring a Xilinx FPGA. The PXIe-5774 PXI FlexRIO Digitizer is useful in those applications that require real-time processing of signals. The NI PXIe-5774 offers a high-performance analog input.
The National Instruments PXIe-5774 is a 12-bit PXI FlexRIO Digitizer that features 2 voltage input channels. The NI PXIe-5774 features DC analog input coupling. The PXIe-5774 has different voltage ranges that can be selected through software as per the requirements of the user’s application. The available ranges for the input voltage are 200 mVpp and 1 Vpp. The DC offset for the voltage ranges is also selectable.
The NI PXIe-5774 PXI FlexRIO Digitizer can be operated in two different modes: dual-channel mode and single-channel mode. Twice the maximum sampling rate can be achieved in single-channel mode as compared to the double-channel mode. The PXIe-5774 features a Molex Nano-Pitch connector for I/O signals. The NI PXIe-5774 FlexRIO Digitizer is equipped with 4 GB of DRAM. The PXIe-5774 PXI FlexRIO Digitizer can be used in various applications, such as medical imaging, particle physics, and scientific instrumentation.
| Model | PXIe-5774 |
|---|---|
| Manufacturer | National Instruments |
| Part Numbers | 785646-01, 785647-01, 785646-02, 785647-02, 785647-11, 785647-12 |
| Type | PXI FlexRIO Digitizer |
| FPGA Type | Kintex UltraScale KU040 or Kintex UltraScale KU060 |
| Analog Input Coupling | DC |
| Voltage Input Channels | 2 |
| Maximum Total Power | 58 W |
| Dimensions | 0.8 in. × 5.1 in. × 8.5 in. |
| Weight | 17.6 oz. |
| Warranty | 2-3 Year Warranty |
| PXIe-5774 Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
Associated part numbers for the PXIe-5774:
145663B-01L, 145663B-02L, 145663D-101L, 145663D-102L, 145663D-202L, 145663E-01L, 145663E-02L, 145663E-101L, 145663E-102L, 145663E-202L, 145663F-01L, 145663F-02L, 146652A-01L, 146652A-02L, 146652A-03L, 146652B-02L, 146652B-03L, 146652B-103L, 146652C-02L, 146652C-03L, 146652C-103L, 146652D-02L, 146652D-03L, 146652D-103L, 149066A-01L, 149066A-02L, 149066A-03L, 149066B-02L, 149066B-03L, 149066B-103L, 149066C-02L, 149066C-03L, 149066C-103L, 149066D-03L, 149066D-103L, 149066E-02L, 785645-01, 785645-02, 785646-01, 785646-02, 785647-01, 785647-02, 785647-11, 785647-12
National Instruments PXIe-5774 Frequently Asked Questions
Question: What is the difference between the 6 part numbers of the PXIe-5774?
Answer: Part numbers 785646-01 and 785646-02 have a KU040 FPGA and a bandwidth of 3 GHz and 1.6 GHz, respectively. Similarly, part numbers 785647-01 and 785647-02 have respective bandwidths of 3 GHz and 1.6 GHz- but they have a KU060 FPGA. Part numbers 785647-11 and 785647-12 have a KU060 FPGA, and bandwidths of 3 GHz and 1.6 GHz respectively- but they also feature Cablesense Technology.
Question: What is the operating temperature range of the PXIe-5774?
Answer: The PXIe-5774 Digitizer operates effectively within a temperature range of 0 °C to 55 °C.
Question: What is the maximum total power of the PXIe-5774?
Answer: The maximum power is 58 W.
| Part Number | FPGA | Bandwidth | Additional Attributes |
| 785646-01 | KU040 | 3 GHz | DC |
| 785647-01 | KU060 | 3 GHz | DC |
| 785646-02 | KU040 | 1.6 GHz | DC |
| 785647-02 | KU060 | 1.6 GHz | DC |
| 785647-11 | KU060 | 3 GHz | W/ Cablesense Technology, DC |
| 785647-12 | KU060 | 1.6 GHz | W/ Cablesense Technology, DC |
PXIe-5774 PDF Manuals
PXIE 5774 DECLARATION OF CONFORMITY.PDF
PXIE 5774 DIMENSIONAL DRAWING.PDF
PXIE 5774 GETTING STARTED GUIDE.PDF
PXIE 5774 LETTER OF VOLATILITY.PDF
PXIE 5774 SAFETY AND EVIRONMENTAL INFORMATION.PDF
