GPIB-232CT-A In Stock | Ships in 5-10 Days
GPIB-232CT-A, 38.4 kb/s maximum RS-232 data transfer rates, GPIB-to-RS232 Controller
Need an Official Quote?
National Instruments GPIB-232CT-A GPIB Serial Controller
Featured with full GPIB controller capability, the NI GPIB-232CT-A (Part Numbers: 776668-01, 776668-02, 776668-03, 776668-04, 776668-05, 776668-06, 776899-01, 776899-31, 776667-01, 776667-02, 776667-03, 776667-04, 776667-05, 776667-06, 776900-01, and 776900-31) provides a PC with a serial port (RS232), a means of talking, listening, and controlling on the GPIB. Moreover, this device can be utilized for quickly interfacing peripherals and other measuring devices to the GPIB.
The National Instruments GPIB-232CT-A is offered in two AC versions (100-120 VAC, 220-240 VAC) and one DC version. For the DC version, an external power supply is delivered with the device. This model comes equipped with a NAT4882 controller chip. This chip enables the NI GPIB-232CT-A for complete IEEE 488.2 standard compatibility. For talking, listening, and controlling on the GPIB, the user can connect their computer`s serial port to the RS-232 port of this device.
The RS-232 serial port can be operated in either S mode or G mode. In its default configuration, the unit comes configured to run in S mode. However, users can change the serial port’s operating method through a DIP switch. In S mode, the attached computer acts as the controlling device. However, in G mode the GPIB-232CT-A is utilized to interface as an RS-232 device as a Listener/Talker.
Each GPIB-232CT-A device can be used with the NI-488.2 driver software- a comprehensive set of drivers and programs for transforming the Microsoft Windows-based PC into a GPIB controller with complete bus management and communication capability. This GPIB Serial Controller has all the logic and software required to implement the electrical and physical specifications of the RS-232 and IEEE 488.
| Model | GPIB-232CT-A |
|---|---|
| Manufacturer | National Instruments |
| Part Numbers | 776668-01, 776668-02, 776668-03, 776668-04, 776668-05, 776668-06, 776899-01, 776899-31, 776667-01, 776667-02, 776667-03, 776667-04, 776667-05, 776667-06, 776900-01, 776900-31 |
| Type | GPIB Serial Controller |
| Data Transfer Rates | up to 38.4 kb/s |
| RAM Buffer | 256 KB |
| Driver | NI-488.2 for Windows 3.1/DOS |
| Dimensions | AC Version: 3.0 by 1.7 by 4.7 in. DC Version: 3.0 by 1.1 by 4.7 in. |
| Weight | 12 oz. |
| Warranty | 2-3 Year Warranty |
| GPIB-232CT-A Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
Associated part numbers for the GPIB-232CT-A:
181930-01B, 181930-31A, 181930-31B, 181930-32, 182534-01, 182534-02
Associated NSNs for the GPIB-232CT-A:
7050-01-471-3176 (7050014713176), 7025-01-566-7146 (7025015667146), 7050-01-471-3176 (7050014713176), 7050-01-471-3176 (7050014713176)
National Instruments GPIB-RS232CT-A Frequently Asked Questions
Question: What are the differences between the eight part numbers for the National Instruments GPIB-232CT-A?
Answer: The eight part numbers for the National Instruments GPIB-232CT-A come in an AC and a DC version, which have varying types of power cords or power supplies. First, there are several part numbers that only come with the GPIB-232CT-A device. Part number 776668-01 is the AC version with a U.S. 120 VAC power cord. Part number 776668-02 is the AC version with a Swiss 220 VAC power cord. Part number 776668-03 is the AC version with an Australian 240 VAC power cord. Part number 776668-04 is the AC version with a Universal Euro 240 VAC power cord. Part number 776668-05 is the AC version with a North American 240 VAC power cord. Part number 776668-06 is the AC version with a United Kingdom 240 VAC power cord. Part number 776899-01 is the DC version with a 115 VAC power supply. Part number 776899-31 is the DC version with a 230 VAC power supply. Then, there are several more part numbers that are the GPIB-232CT-A device with NI-488.2 for Windows 3.1/DOS. Part number 776667-01 is the AC version with a U.S. 120 VAC power cord. Part number 776667-02 is the AC version with a Swiss 220 VAC power cord. Part number 776667-03 is the AC version with an Australian 240 VAC power cord. Part number 776667-04 is the AC version with a Universal Euro 240 VAC power cord. Part number 776667-05 is the AC version with a North American 240 VAC power cord. Part number 776667-06 is the AC version with a United Kingdom 240 VAC power cord. Part number 776900-01 is the DC version with a 115 VAC power supply. Part number 776900-31 is the DC version with a 230 VAC power supply.
Question: Which accessories are required for the NI GPIB-232CT-A?
Answer: The NI GPIB-232CT-A requires either a U.K., North American, U.S., Universal European, Australian, or Swiss power cord for the AC version. The DC version requires a 100-120 VAC, 9 V, 1 A Wall-mount power supply or a 220-240 VAC, 9 V, 1 A Desktop Power Supply. Both versions also require a 1, 2, or 4 m Type X2 double-shielded GPIB cable and a 1, 2, or 4 m shielded RS-232 DTE-to-DTE cable.
Question: Which type of connector does the GPIB-232CT-A have?
Answer: The GPIB-232CT-A RS-232 serial port utilizes a male 9-pin D-Subminiature connector with a DTE interface configuration.
Question: What is different between the GPIB-232CT-A and the GPIB-232CT?
Answer: The GPIB-232CT-A is an improved variation of the GPIB-232CT with an internal power supply, tinier size, complete NI-488.2 software driver, and compliance with IEEE 488.2 with the NAT4882 GPIB controller chip.
GPIB-232CT-A PDF Manuals
ARCHIVED GETTING STARTED WITH LABWINDOWS CVI.PDF
ARCHIVED GETTING STARTED WITH MEASUREMENT STUDIO LABWINDOWS CVI.PDF
ARCHIVED GETTING STARTED WITH YOUR GPIB-232CT-A AND THE NI 488.2 SOFTWARE FOR MACOS.PDF
ARCHIVED GPIB 232 485CT A USER MANUAL AND SPECIFICATIONS.PDF
ARCHIVED GPIB-232CT-A AND GPIB 232CV A OEM SPECIFICATION GUIDE.PDF
ARCHIVED GPIB-232CT-A AND NI 488.2 FOR MS DOS WINDOWS.PDF
ARCHIVED GPIB-232CT-A IBCL EPROM INSTALLATION GUIDE.PDF
ARCHIVED GPIB 232CT USER MANUAL.PDF
ARCHIVED GPIB CT IBCL REFERENCE MANUAL.PDF
ARCHIVED INSTALLATION GUIDE FOR THE GPIB RF.PDF
ARCHIVED LABVIEW FUNCTION AND VI REFERENCE MANUAL.PDF
ARCHIVED LABVIEW INSTRUMENT I O VI REFERENCE MANUAL.PDF
ARCHIVED LABVIEW USER MANUAL.PDF
ARCHIVED NI 488 AND NI 488.2 SUBROUTINES FOR PASCAL.PDF
