NI 781041-01 Device For PXI Remote Control | Apex Waves | ImageNI 781041-01 Device For PXI Remote Control | Apex Waves | Image781041-01 New781041-01 | Legacy, Refurbished and New Surplus
NI 781041-01 Device For PXI Remote Control | Apex Waves | Image
NI 781041-01 Device For PXI Remote Control | Apex Waves | Image
781041-01 New
781041-01 | Legacy, Refurbished and New Surplus
Same Day Calibration Available
2-3 Year Warranty Included
Free Ground Shipping

Or speak to a sales representative for additional information:


781041-01 In Stock | Ships Today

781041-01, PCI Express x4, 100 m, 60 grams, PCIe-8375 Device For PXI Remote Control
4.6/5 | 11 ratings
Fast Quote
Quoted Price

Need an Official Quote?



National Instruments 781041-01 Device for PXI Remote Control.

The part number 781041-01 from National Instruments is the identifying part number for the PCIe-8375 Device for PXI Remote Control. This PCle controller is an PCI express x4 device that requires a PCI express slot supported by MXI-Express x4 Fiber-Optic cable with a maximum cable distance of 100 meters, making it suitable to connect to devices in distance while also making it excellent for industrial use as well. This device is completely compatible with PCI express specification that makes this device a good choice for a variety of applications. This device requires a host computer that supplies a PCI Express clock that adheres to the PCI Express Specification. It may not be compatible with systems with noncompliant clocks, particularly systems with clocks whose frequency
peaks over 100 MHz

The 781041-01 Device for PXI Remote Control has power requirements of 550 mA typical current and 720 mA maximum current in +3.3 Volts, 0 A typical current and a maximum current of 0 A in +3.3 Vaux while 200 mA typical current and 320 mA maximum current in +12 V. With these power requirements, this PXI device can run efficiently with constraints of PXI standard slots while maintaining a high performance as well.

This device is engineered to operate in an environment of 0 degrees Celsius to 55 degrees Celsius under the IEC-60068-2-1 and IEC-60068-2-2 standard. It also has an optimum storage temperature of -20 degrees Celsius  to 70 degrees Celsius tested under the IEC-60068-2-1 and IEC-60068-2-2 standard. Its operating relative humidity is 10% to 90%, noncondensing tested under the IEC-60068-2-56 standard while storage relative humidity is 5% to 95%, noncondensing tested under the IEC-60068-2-56 standard.

This PCle remote controller is designed for indoor use only and can be mounted at a maximum altitude of 2000 metres with a pollution degree of 2. It does not feature IP (ingress protection), which means that this device cannot be used in environments where dust and moisture are common. This device is compliant with IEC 61010-1, EN 61010-1, UL 61010-1 and CSA 61010-1 safety standard that makes it suitable for measurement, control, and laboratory use. It is also electromagnetically compatible tested under the EN 61326 and EN 55011 standard.

Part Number781041-01
Model NamePCIe-8375
Part TypeDevice For PXI Remote Control
Slot TypePCI Express x4
Cable SupportMXI-Express x4 Fiber-Optic
Maximum Distance100 m
LED Indicators1 Tri-color LED
Power Requirements3.3 V, +3.3 VAux, +12 V - 550 mA, 0 A, 200 mA
Dimensions3.5 in. × 2.72 in.
Weight60 grams

  781041-01 PDF Manuals
