National Instruments 779725-03 Chassis Remote Control Cable
Part Number 779725-03 is the identifying part number for the National Instruments MXI-Express Cable, a Chassis Remote Control Cable. These cables connect a host interface to a PXI or PXI Express channel. The chassis remote control cable defined by the 779725-03 also comes with different part numbers, namely 779500-01, 779500-03, 778959-10, 779725-03, 779500-07, 785549-03, 785550-01, 782317-03, 779725-07, 778959-30, 785550-03, 782317-05, 778959-200, 781042-100, 783329-10, 783329-30, and 783329-100. Likewise, there are multiple available MXI communication levels namely MXI-Express Gen 1 x1, MXI-Express Gen 1 x4, MXI-Express Gen 2 x8, MXI-Express Gen 3 x4, and MXI-Express Gen 3 x8.
The cables represented by the 779725-03 comes in the following length: 1 m, 3 m, 5 m, 7 m, 10 m, 30 m, 100 m, and 200 m. These cables are used for data communication in systems where more than one chassis is operated in a tandem arrangement. The simplest cable supports Gen 1 x 1 communication and is available on 1 m, 2 m, or 200 m version. On the other hand, the most advanced cable supports Gen 2 x 8 communication level and measures 100 m in length.
To properly understand the length and communication levels of cables such as the 779725-03, you can consider the following guide. The part numbers with a communication level of MXI Gen 1x1 include; 779500-01 (1 m), 779500-03 (3 m), 778959-10 (10 m), 779500-07 (7 m), and 778959-200 (200 m). Likewise, the part numbers with a communication level of MXI Gen 1x4 include 779725-03 (3 m) and 779725-07 (7 m). Similarly, the part numbers with a communication level of MXI Gen 2x8 include 782317-03 (3 m) and 782317-05 (5 m). Furthermore, the part number with a communication level of MXI Gen 3x4 is the 785549-03 (3 m). Lastly, the part numbers with a communication level of MXI Gen 3x8 are 785550-01 (1 m) and 785550-03 (3 m).
| Part Number | 779725-03 |
|---|---|
| Model Name | MXI-Express Cable |
| Part Type | Chassis Remote Control Cable |
| Cable Length | 1 m, 3 m, 7 m, 10 m, 30 m, 100 m, or 200 m |
| MXI Communication Level | MXI-Express Gen 1 x1, Gen 1 x4, Gen 2 x8, Gen 3 x4, or Gen 3 x8 |
| Compatible Models | PXI or PXI Express Chassis |
| Primary Use | Remote Control of Chassis |
| Supports More Than One Chassis | Yes |
| Simplest Cable | Cable supporting Gen 1 x 1 communication |
| Most Advanced Cable | Cable supporting Gen 2 x 8 communication level |
