National Instruments PXI-5402 PXI Waveform Generator
The National Instruments PXI-5402 (Part Numbers: 779655-01, 192887E-01L) is a high-performance 20 MHz function generator designed for precise waveform generation in automated test and measurement applications. Equipped with a 14-bit digital-to-analog converter (DAC) and direct digital synthesis (DDS) technology, it delivers accurate and customizable waveforms with minimal distortion.
The PXI-5402 can generate a range of standard functions, such as sine, square, triangle, and ramp waves, in addition to DC signals and pseudorandom noise, with a maximum output voltage of ±5 V (ACpk + DC). With a 50 Ω load, its output amplitude ranges from 5.64 mVpk-pk to 10 Vpk-pk, and with a high-impedance load, it ranges from 11.28 mVpk-pk to 20 Vpk-pk. It provides versatility for a range of testing applications with software-selectable output impedance (50 Ω or 75 Ω) and adjustable phase (-180° to +180°). In order to generate complicated signals, additional PXI-5402 units can be coupled together as the device also supports waveform summation.
The PXI-5402 provides maximum frequencies of 20 MHz for typical functions and a frequency resolution of 0.355 μHz for accurate frequency management. For sine, square, and user-defined waveforms, it offers a maximum sample rate of 400 MS/s; for ramp, triangle, and noise signals, it offers a maximum sample rate of 100 MS/s.
The PXI-5402 has the ability to generate waveforms and also has synchronization functionality via its SYNC OUT/PFI 0 and PFI 1 ports. It supports single, continuous, stepped, and burst trigger modes and may function as both a trigger source and receiver. With minimum pulse widths of 25 ns, the device enables precise timing and low jitter (<2 MHz: 0.01% of period + 500 ps, average; ≥2 MHz: 0.1% of period + 70 ps).
Input and output connectors for synchronization and reference are included with the PXI-5402 to guarantee compatibility with external systems and devices. With a maximum input overload protection of ±10 V (ACpk + DC), it enables input voltages ranging from 0.2 Vpk-pk to 2.8 Vpk-pk for square waveforms and 0.63 Vpk-pk to 2.8 Vpk-pk for sine waves.
Model | PXI-5402 |
---|---|
Manufacturer | National Instruments |
Part Numbers | 779655-01, 192887E-01L |
Type | PXI Waveform Generator |
Maximum Bandwidth | 20 MHz |
Maximum Update Rate | 100 MS/s |
Analog Output Resolution | 14 bits |
Output Channels | 1 |
Warranty | Three Year Warranty |
PXI-5402 Manual | User Manual and Maintenance Manual Available for Download |
Price | Contact a sales representative for a quote. |
Associated part numbers for the PXI-5402:
188524J-15L, 188524M-15L, 192378A-01, 192378B-01, 192378C-01, 192378H-01L, 192887A-01, 192887B-01, 192887C-01, 192887D-01L, 192887E-01L, 192887F-01L, 195176A-01, 200033A-01, 779655-01
National Instruments PXI-5402 Frequently Asked Questions
Question: Can the PXI-5402 generate pseudorandom noise or DC signals?
Answer: Yes, the PXI‑5402 is capable of generating psuedorandom noise and DC signals.
Question: What is the effective sample rate of the PXI 5402?
Answer: The PXI 5402 has a 400 MS/s effective sample rate.
Question: What is the sine and square wave generation rate on the NI PXI-5402?
Answer: The NI PXI-5402 has a 20 MHz sine and square wave generation.
Question: Is it possible to skip pulses with the PXI-5402?
Answer: No, to skip pulses, it is necessary to use an arbitary waveform generator or FPGA DIO.
PXI-5402 PDF Manuals
MAINTAIN FORCED AIR COOLING NOTE TO USERS.PDF
NI 5402 5406 CALIBRATION PROCEDURE.PDF
NI PXI PCI 5402 5406 SPECIFICATIONS.PDF
NI SIGNAL GENERATORS GETTING STARTED GUIDE.PDF
NOTE TO USERS RETROFITTING YOUR PXI MODULE.PDF
PCI PXI-5402 LETTER OF VOLATILITY.PDF
