PXI-8186, 2.2 GHz Pentium 4-M Processor, PXI Controller
Need an Official Quote?
National Instruments PXI-8186 PXI Controller
Featured with an integrated GPIB (IEEE 488.2) interface, the National Instruments PXI-8186 (Part Numbers: 778755-00, 778755-01, 778755-02, 778755-33, 778842-00, 778842-01, 778842-02, 778842-33) is a Pentium 4 based Embedded Controller that can be used in any PXI or CompactPCI system. The powerful hardware configuration of this Controller makes it a viable solution for a broad range of intensive applications. The NI PXI-8186 comes equipped with a 2.2 GHz Pentium 4-M CPU. This PXI Controller has 512 KB on-die cache, 256 MB of RAM and a 30 GB hard drive.
To deliver realistic, intense 3D graphics, fast rendering, high detail, and smooth motion, the PXI 8186 Controller features an integrated Intel Extreme Graphics core. Thus, the user will not need an additional video card. This Controller utilizes double-data-rate SDRAM (DDR-SDRAM). The SDRAM doubles memory bandwidth since it transfers data twice per cycle. The NI PXI 8186 comes equipped with one 10/100BaseTX Port, one IEEE 1284 Parallel Port, one PCI-GPIB/TNT Port, two USB 2.0 Ports, one PS/2 connector, two Serial Ports, and a 2.5 in., 9.5 mm 30 GB Internal Hard Drive.
The standard version of the NI PXI 8186 Embedded Controller has an operating temperature of 5 to 40 °C. However, this PXI Controller is also offered in the extended-temperature version (Part Number: 778842-01), which has an operating temperature of 0 to 55 °C. As far as its physical dimensions are concerned, the PXI-8186 is a 3U-size PXI module, with dimensions of 8.1 by 13 by 21.6 cm. Also, the device has a weight of 2.2 lbs. The NI PXI-8186 requires one system slot and three controller slots to be installed in a compatible PXI chassis.
The PXI-8186 operates using multiple software. One of them is NI-DAQ which hosts a library of functions which can be utilized from your application development environment (ADE) of choice-ADEs such as LabVIEW, Measurement Studio, and LabWindows/CVI. Another software which the device operates on is the NI-VISA which is in creating applications and instrument drivers.
PXI-8186 Obsolete Status has been announced by National Instruments, but the Controller will still be available for purchase and repairs by Apex Waves.
| Model | PXI-8186 |
|---|---|
| Part Numbers | 778755-00, 778755-01, 778755-02, 778755-33, 778842-00, 778842-01, 778842-02, 778842-33 |
| Manufacturer | National Instruments |
| Type | PXI Controller |
| Slot Requirements | 1 system slot and 3 controller expansion slots |
| CPU | 2.2 GHz Pentium 4-M |
| Standard RAM | 256 MB |
| Dimensions | 3.2 x 5.1 x 8.5 in. |
| Weight | 2.2 lb. |
| Warranty | Thre Year Warranty |
| PXI-8186 Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
Associated part numbers for the PXI-8186:
191689B-01, 191689C-01, 778755-00, 778755-01, 778755-011, 778755-02, 778755-33, 778842-00, 778842-01, 778842-02, 778842-33, 1.89792E-07, 1.89792E-17, 189792B-712, 189792C-012, 189792C-022, 189792C-032, 189792C-612, 189792C-622, 189792C-712, 189792C-722, 189792D-012, 189792D-022, 189792D-612, 189792D-622, 189792D-712, 189792D-722, 189792E-612, 189792E-622, 189792E-712, 189792E-722, 189792F-012, 189792F-022, 189792F-612, 189792F-622, 189792F-712, 189792F-722, 189792G-022, 189792G-612, 189792G-622, 189792G-712, 189792G-722, 189792H-622, 189792H-722, 189792J-022, 189792J-622, 189792J-722, 191689A-01
Associated NSNs for the PXI-8186:
5998-01-528-0801 (5998015280801)
National Instruments PXI-8186 Frequently Asked Questions
Question: Why are there so many part numbers for the PXI-8186?
Answer: There is a base model and an extended temperature version for the PXI-8186 with various operating systems. Part number 778755-01 is a base model with Windows XP (English) installed, while part number 778842-01 is an extended temperature version with Windows XP (English) installed. Next, part number 778755-02 is the base model with Windows 2000 (English) installed and part number 778842-02 is the extended temperature version with Windows 2000 (English) installed. Part number 778755-33 is the base model with LabVIEW Real-Time embedded software, while part number 778842-33 is the extended temperature version with LabVIEW Real-Time embedded software. Lastly, part number 778755-00 is the base model with Localized OS installed and part number 778842-00 is the extended temperature model with Localized OS installed.
Question: Can the RAM be upgraded on the NI PXI 8186 Embedded Controller?
Answer: On the NI PXI 8186 Embedded Controller, the RAM can be upgraded to 512 MB or 1 GB.
Question: What is the size of the hard drive on the PXI 8186 Controller?
Answer: The hard drive on the PXI 8186 Controller is 30 GB minimum for the base unit and 20 GB minimum for the extended temperature option.
Question: What is the difference in the temperature range for the base model and the extended temperature version of the NI PXI-8186?
Answer: The base model of the NI PXI-8186 has an operating temperature ranging from 5 to 40 degrees C and a storage temperature ranging from -20 to 60 degrees C. The extended temperature model of the NI PXI-8186 has an operating temperature ranging from 0 to 55 degrees C and a storage temperature ranging from -40 to 85 degrees C.
PXI-8186 PDF Manuals
ARCHIVED NI 8186 INSTALLATION GUIDE.PDF
ARCHIVED NI PXI-8186 8187 INSTALLATION GUIDE.PDF
ARCHIVED NI PXI-8186 8187 USER MANUAL AND SPECIFICATIONS.PDF
ARCHIVED NI PXI-8186 MEMORY MODULE REMOVAL GUIDE.PDF
ARCHIVED NI PXI-8186 USER MANUAL.PDF
ARCHIVED NI PXI 8195 8196 USER MANUAL AND SPECIFICATIONS.PDF
PXI EXPRESS EMBEDDED CONTROLLERS PRODUCT FLYER.PDF
