PXIe-5654, 250 kHz to 20 GHz, PXI RF Analog Signal Generator
Need an Official Quote?
National Instruments PXIe-5654 PXI RF Analog Signal Generator
The 20 GHz PXIe‑5654 (Part Numbers: 783126-01, 783126-02, 783127-01, 783127-02, 784776-01, 784776-02, 784777-01, and 784777-02) is an RF Analog Sign Generator from National Instruments. This model is designed for application testing in RFIC characterization, satellite test, and radar systems. The NI PXIe‑5654 comes with an ideal combination of a great phase noise and analyzer tuning time of 1 ms. The PXIe‑5654 is also suitable for applications such as blocker test/receiver desensitization, high-performance intermodulation distortion measurements, and a variety of electronic warfare/defense applications.
The NI PXIe-5654 has varying specifications because of the many part numbers. The user can find a PXIe-5654 model that supports a frequency range from 250 kHz to 20 GHz, a frequency resolution range from <3 Hz to 6 Hz, and a typical tuning time of 1 ms, 1.5 ms, or 100 us. The module width size is 3 or 5, depending on the part number. This model offers a maximum output power of 12 dBm. The NI PXIe‑5654 can be combined with other PXI modules to design automated test systems for radar, RF integrated circuits (RFICs), and automotive test applications.
This module has a Voltage Standing Wave Ratio (VSWR) feature. The VSWR allows it to be compatible with the PXIe-5696 VSWR. The supported modulation types include amplitude modulation (AM), frequency modulation (FM), phase modulation (PM), and pulse modulation. This module has an internal reference output frequency 1 and 2 of 10 MHZ and 100 MHz respectively.
| Model | PXIe-5654 |
|---|---|
| Part Numbers | 783126-01, 783126-02, 783127-01, 783127-02, 784776-01, 784776-02, 784777-01, 784777-02 |
| Manufacturer | National Instruments |
| Type | PXI RF Analog Signal Generator |
| Module Width | 3 or 5 |
| Maximum Output Power | 15 dBm or 27 dBm |
| Frequency Range | 250 kHz to 10 GHz or 250 kHz to 20 GHz |
| Dimensions | 8.4 x 2.4 x 5.1 in. |
| Weight | 46.8 oz. |
| Warranty | 2-3 Year Warranty |
| PXIe-5654 Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
Associated part numbers for the PXIe-5654:
154027A-01L, 154027B-01L, 154027C-01L, 154027D-01L, 154027E-01L, 154027F-01L, 154027G-01L, 154030A-01L, 154030B-01L, 154030C-01L, 154030D-01L, 154030E-01L, 154033A-01L, 154033B-01L, 154033C-01L, 154033D-01L, 154033E-01L, 154036A-01L, 154036B-01L, 154036C-01L, 154036D-01L, 154036E-01L, 154036F-01L, 154036G-01L, 156072F-02L, 157089A-01L, 157089A-02L, 157089A-03L, 157089A-04L, 157089B-01L, 157089B-02L, 157089B-03L, 157089B-04L, 157089C-01L, 157089C-02L, 157089C-03L, 157089C-04L, 157089D-01L, 157089D-02L, 157089D-03L, 157089D-04L, 157089E-01L, 157089E-02L, 157089E-03L, 157089E-04L, 157090A-01L, 157091A-01L, 157092A-01L, 196945E-01L, 196945F-01L, 200130A-01, 200130B-01, 200395A-01, 200475A-01, 200566A-01, 783126-01, 783126-02, 783127-01, 783127-02, 783127-03, 783127-04, 784776-01, 784776-02, 784777-01, 784777-02, 785089-01, 785090-01
National Instruments PXIe-5654 Frequently Asked Questions
Question: Why does the PXIe-5654 have multiple part numbers?
Answer: The PXIe-5654 has varying specifications available. Part number 783126-01 has 15 dBm maximum output power, 250 kHz to 10 GHz frequency range, 1 ms typical tuning time, and a module width of 3. Part number 783126-02 has the same specifications but with 100 us typical tuning time. Part number 783127-01 has 15 dBm maximum output power, 250 kHz to 20 GHz frequency range, 1 ms typical tuning time, and a module width of 3. Next, part number 783127-02 has the same specifications as the previous part number but instead has 100 us typical tuning time. Part number 784776-01 has 27 dBm maximum output power, 250 kHz to 10 GHz frequency range, 1 ms typical tuning time, and a module width of 5. Part number 784776-02 has the same specifications as the previous part number but has 100 us typical tuning time. Then, part number 784777-01 has 27 dBm maximum output power, 250 kHz to 20 GHz, 1 ms typical tuning time, and a module width of 5. Finally, part number 784777-02 has the same specifications as the previous part number but with 100 us typical tuning time instead.
Question: How many LEDs are on the NI PXIe-5654?
Answer: The NI PXIe-5654 has two multicolor LEDs.
Question: Which types of modulation are supported by the PXIe-5654?
Answer: The PXIe-5654 supports pulse modulation, amplitude modulation (AM), phase modulation (PM), and frequency modulation (FM).
Question: Which optional items can be used with the NI PXIe-5654?
Answer: The NI PXIe-5654 has the following optional items: a 1 N m standard SMA torque wrench and the PXIe-5696 amplitude extender module.
PXIe-5654 PDF Manuals
MAINTAIN FORCED AIR COOLING NOTE TO USERS.PDF
NI PXIE 5654 GETTING STARTED GUIDE.PDF
NI PXIE 5654 LETTER OF VOLATILITY.PDF
NI PXIE 5696 GETTING STARTED GUIDE.PDF
PXIE 5654 CALIBRATION PROCEDURES.PDF
PXIE 5654 WITH PXIE 5696 CALIBRATION PROCEDURE.PDF
