National Instruments PXIe-7976R PXI FPGA Module for FlexRIO
The National Instruments PXIe-7976R (Part Number: 783625-01) is a PXI FPGA Module for FlexRIO. This module comes equipped with 2 gigabytes of RAM and supports up to 10.5 GB/s theoretical data transfer rates. The PXIe-7976R features a Kintex-7 410T FPGA, which includes 28,620 kbits of block RAM (BRAM), 1,540 DSP slices, and 254,200 LUTs.
This module has 136 channels that are configurable as 68 differential channels or 136 single-ended channels. The general-purpose channels incorporated in this module are segregated into three banks, out of which two banks (Bank 0 and Bank 1) contain 48 channels, whereas the remaining 40 channels are in Bank 2. The PXIe-7976R can offer a maximum data rate of 400 Mb/s while operating in single-ended mode and up to 1 Gb/s data rate is possible for low voltage differential signals (LVDS). This module has 5 single-region and 6 multi-region clock inputs.
| Model | PXIe-7976R |
|---|---|
| Manufacturer | National Instruments |
| Part Number | 783625-01 |
| Type | PXI FPGA Module for FlexRIO |
| FPGA | Kintex-7 410T |
| General-Purpose Channels | 136 |
| Onboard DRAM | 2 GB |
| Form Factor | x8 PXI Express, specification v2.1 compliant |
| Dimensions | 7.4 x 5.1 in. |
| Weight | 6.7 oz (190 g) |
| Warranty | 2-3 Year Warranty |
| PXIe-7976R Manual | User Manual and Maintenance Manual Available for Download |
| Pricing | Contact a Sales Representative for a quote. |
Associated NSNs for the PXIe-7976R:
5998-01-675-6773 (5998016756773)
Frequently Asked Questions
Q: What are the key features of the NI PXIe-7976R FPGA Module for FlexRIO?
A: The NI PXIe-7976R is a high-performance PXI FPGA Module designed for FlexRIO applications. It features a Kintex-7 410T FPGA, 2 GB onboard DRAM, and 136 configurable I/O channels. The module supports high-speed data transfer up to 10.5 GB/s, making it ideal for real-time signal processing, hardware-in-the-loop (HIL) testing, and high-throughput measurement applications.
Q: How many digital input and output channels does the PXIe-7976R have?
A: The PXIe-7976R has 136 general-purpose channels, which can be configured as 136 single-ended channels or 68 differential channels. These channels are divided into three banks (Bank 0 and Bank 1 with 48 channels each, and Bank 2 with 40 channels) for maximum flexibility in signal acquisition and generation.
Q: What is the maximum data rate for the NI PXIe-7976R in single-ended and differential modes?
A: The NI PXIe-7976R supports high-speed data transfer, offering a maximum data rate of 400 Mb/s in single-ended mode and up to 1 Gb/s for Low Voltage Differential Signaling (LVDS). This allows engineers and researchers to perform fast, reliable signal processing for advanced applications such as RF testing, image processing, and real-time control.
Q: What PXI slots are compatible with the NI PXIe-7976R?
A: The PXIe-7976R is an x8 PXI Express module, fully compliant with PXI Express Specification v2.1. It is compatible with x4, x8, and x16 PXI Express or PXI Express hybrid slots, ensuring seamless integration into modern PXI-based test and measurement systems.
