REM-11102, 2-, 3-, 4-Wire Current Input Module for Remote I/O
Need an Official Quote?
National Instruments REM-11102 Current Input Module for Remote I/O
Designed for remote I/O systems, the NI REM-11102 (Part Number: 784747-01) is a 4-channel Current Input Module. This module supports 2-wire, 3-wire, and 4-wire configurations and can be used in a variety of control applications. The REM-11102 is deployed as part of a larger system called National Instruments Remote I/O. The NI REM-11102 module can be used with other remote I/O modules for the construction of a low-cost yet reliable control system. The National Instruments REM-11102 Current Input Module supports connectivity through spring terminals– a provision that enables fast deployment.
This Current Input Module offers simultaneous sampling, has a selectable input range, and an integrated power supply for sensors. The NI REM-11102 allows you to select an input range of 4 to 20 mA, 0 to 20 mA, and ±20 mA. The analog-to-digital converter incorporated in this module is a 16-bit converter that can operate with 31.25 μs conversion time. For communications, the REM-11102 Current Input Module draws around 120 mA of power from the bus connector. The total power consumption is 1.5 watts.
The National Instruments REM-11102 Current Input Module comes with a bus connector. This module can transmit or receive data at rates up to 100 MBits/s. By using the NI REM-11102, you can offload your main controllers so they can process more demanding and important applications in an optimized way. You can have an entire remote I/O system designed and integrated into an existing control system with the help of EtherCAT.
Model | REM-11102 |
---|---|
Manufacturer | National Instruments |
Part Number | 784747-01 |
Type | Current Input Module for Remote I/O |
Input Ranges | 0 mA to 20 mA, 4 mA to 20 mA, and ±20 mA |
Input Channels | 4 |
Input Resolution | 16-bit |
Typical Power Consumption | 1.5 W |
Dimensions | 4.96 in. x 1.38 in. x 2.13 in. |
Weight | 5.11 oz. |
Warranty | 2-3 Year Warranty |
REM-11102 Manual | User Manual and Maintenance Manual Available for Download |
Price | Contact a sales representative for a quote. |
Associated part numbers for the REM-11102:
750545-01, 784747-01
REM-11102 PDF Manuals
NI REM-11102 GETTING STARTED GUIDE.PDF
REMOTE I O VENDOR CONFIGURATION GUIDE.PDF
