National Instruments SCXI-1332 Matrix Terminal Block
The NI SCXI-1332 (Part Number: 777687-32) is a front-mount Terminal Block that provides direct association to transducers at the screw terminals situated inside a completely protected enclosure in or at front-mounted BNC connectors. Strain-relief clasps hold the signal wires securely in place. The user can pick either the TC-2095 or BNC-2095 rack-mount terminal pieces for mini thermocouple connectors or BNC connectors. These terminal blocks are perfect answers for high-channel-count temperature or voltage applications. TBX DIN-rail mount terminal blocks are a contrasting option to the SCXI-1332 Terminal Block, which attach specifically to the front of an SCXI module. The TBX framework incorporates protected links that associate the front I/O connector of a SCXI module to a TBX terminal block.
The user can utilize the framework extension link with the SCXI-1332 terminal block and SCXI-1127 and SCXI-1128 switch modules to expand four lines of 2-wire signals. For instance, if the user must extend a matrix from a 4x8 to an 8x8 configuration, then they require one framework extension link, notwithstanding the additional switch module. This link is also utilized with the SCXI-1335 terminal piece to extend matrix columns with the SCXI-1129.
This Terminal Block offers speedy, simple associations, strain-relief clamps for dependable wiring, connectivity alternatives including BNC and thermocouple plugs, shielded front-mount terminal pieces, rack and DIN-rail mount options, terminal piece options for particular estimation types, an onboard temperature sensor for cold-junction compensation, isothermal development for high-exactness thermocouple estimations, high-voltage attenuation, AC/DC coupling, bridge offset nulling, shunt calibration, and current inputs.
| Model | SCXI-1332 (777687-32) |
|---|---|
| Manufacturer | National Instruments |
| Type | Matrix Terminal Block |
| For use with: | SCXI-1127 or SCXI-1128 switch modules |
| Configuration | 8X4 Matrix |
| Warranty | 2-3 Year Warranty |
| SCXI-1332 Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
Associated part numbers for the SCXI-1332:
184999B-01, 184999C-01, 187333A-01, 777687-32
National Instruments SCXI-1332 Frequently Asked Questions
Question: What devices is the SCXI-1332 designed to work with?
Answer: The SCXI-1332 terminal block is designed to work with and configure the SCXI-1127/1128 module as a 4 × 8, 2-wire matrix.
Question: What should I do if the SCXI 1332 appears damaged when I pull it out of the box?
Answer: If your SCXI 1332 appears to be damaged, you should return the unit right away.
Question: What tools are usually needed to set up the NI SCXI-1332?
Answer: To set up the NI SCXI-1332, in addition to the software and hardware needed, you will also need 1/8 in. flathead screwdriver, Numbers 1 and 2 Phillips screwdrivers, long-nose pliers, a wire cutter, a wire insulation stripper, and matrix expansion cables—one cable needed to expand the number of columns, two cables needed to expand the number of rows.
SCXI-1332 PDF Manuals
NI SCXI 1127 SPECIFICATIONS.PDF
NI SCXI 1128 SPECIFICATIONS.PDF
NI SCXI-1332 INSTALLATION INSTRUCTIONS.PDF
SCXI 1127 1128 USER MANUAL.PDF
