WSN-3214, 4-Channel, 2 DIO Channels, Strain/Bridge Node for WSN
Need an Official Quote?
National Instruments WSN-3214 Strain/Bridge Node for WSN
Designed for National Instruments Wireless Sensors Networks, the NI WSN-3214 (Part Numbers: 781636-01, 781636-02, 150262C-04L) is a Strain/Bridge Node. The WSN-3214 offers 4 analog input channels. You can configure this Strain/Bridge Node for half-, full-, or quarter-bridge completion on a per-channel basis. Moreover, the NI WSN-3214 can be configured to provide strain gauge measurements. This Strain/Bridge Node allows you to define waveform size, sample rate, and waveform interval, since it comes with a flexible analog front end.
The high-resolution and high-speed analog input modes make the WSN-3214 an ideal solution for unique application requirements. Users can deploy this Strain/Bridge Node in a suitable orientation with the help of mounting accessories by NI. The NI WSN-3214 is deployed with other WSN devices that include a WSN gateway. In this system, signals are received and analyzed wirelessly. Each gateway can handle a maximum of 36 wireless nodes.
You can construct an NI WSN system by using a separate host PC running on Microsoft Windows or a CompactRIO Chassis. These operating systems can connect to a Wireless Network System to display status information, real-time measurements, as well as the configuration of the wireless node. You can mount your WSN-3214 Strain/Bridge Node on a 35 mm DIN rail or on a panel. Kit accessories to mount this Strain/Bridge Node can be acquired separately from National Instruments. This model is designed for wireless connectivity and has a provision to be operated by a battery. In its optimum configuration, the WSN-3214 requires a battery replacement or recharge once in three years. However, this device supports redundant supplies and can be powered through an external supply as well.
WSN-3214 Mature Status has been announced by National Instruments, but the Strain/Bridge Node will still be available for purchase and repairs by Apex Waves.
Model | WSN-3214 |
---|---|
Manufacturer | National Instruments |
Part Numbers | 781636-01, 781636-02, 150262C-04L |
Type | Strain/Bridge Node for WSN |
Channels | 4 |
ADC Resolution | 20 bits |
Voltage Range | 5 to 30 V |
Calibration Interval | 3 years |
Weight | Without antenna: 8.5 oz. With antenna: 9 oz. |
Warranty | 2-3 Year Warranty |
WSN-3214 Manual | User Manual and Maintenance Manual Available for Download |
Price | Contact a sales representative for a quote. |
Associated part numbers for the WSN-3214:
150123A-01L, 150123B-01L, 150123C-01L, 150123D-01L, 150262A-01L, 150262A-04L, 150262B-01L, 150262B-04L, 150262C-01L, 150262C-04L, 150262D-01L, 150262D-04L, 704118B-01, 781636-01, 781636-02, 781636-11, 781636-12
