PCIe-6374 Request for Availablility
PCIe-6374, 4 AI, 2 AO, 24 DIO, Multifunction I/O Device
Need an Official Quote?
National Instruments PCIe-6374 Multifunction I/O Device
The PCIe-6374 (Part number: 785817-01) is a high-performance Multifunction I/O Device from National Instruments. This device incorporates a PCI Express Bus Connector. The NI PCIe-6374 offers the flexibility to sample the data simultaneously across all channels. This model has a sampling rate of 3.57 MS per second. This value of sampling rate is based per channel. The device comes with four analog input channels. These channels are differential. The NI PCIe-6374 Multifunction I/O Device additionally has two analog output channels.
The NI PCIe-6374 device comes with a built-in ADC, which has a resolution of sixteen bits. The normal warm-up time of the device is fifteen minutes. The recommended calibration interval for the PCIe 6374 device is a time span of two years. The module is a small device and has a minimal weight. The physical dimensions are 6.60 inches x 4.38 inches. The NI PCIe 6374 Multifunction I/O Device weighs around 110 grams.
The NI PCIe-6374 Multifunction I/O Device includes four counters. These counters have a 32 bit resolution. The counters enable the user to implement the mechanism for triggering requirements. This device includes both analog and digital triggering capabilities. The NI PCIe-6374 Multifunction I/O Device also comes with the DAQ Express software. This software enables the users to complete various measurements and analysis procedures with ease. The instrument can be used for a wide range of applications at the industrial level, which includes manufacturing and testing requirements for different types of telecom equipment.
| Model | PCIe-6374 |
|---|---|
| Manufacturer | National Instruments |
| Part Numbers | 785817-01 |
| Series | X Series |
| Type | Multifunction I/O Device |
| Analog Input Channels | 4 (16-Bit, 3.571 MS/s) |
| Analog Output Channels | 2 (16-Bit, 3.3 MS/s) |
| Digital Inputs | 16 |
| Digital Outputs | 8 |
| Timing I/O | 4 Counter/Timer I/O (32 bits, 100 MHz) |
| Frequency Generator Channels | 1 |
| Phase-Locked Loop (PLL) | 1 |
| I/O Connector | 68-Pos Right Angle Single Stack PCB-Mount VHDCI (Receptacle) |
| Power Requirements | +3.3 V, +12 V -- 1 A, 4.0 W, 13.2 W |
| Dimensions | 6.60 in. × 4.38 in. |
| Weight | 0.24 lb. |
| Driver Software | NI-DAQmx 9.0 |
| Warranty | 2-3 Year Warranty |
| PCIe-6374 Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
Associated part numbers for the PCIe-6374:
146299A-02L, 146305A-01L, 785817-01
National Instruments PCIe-6374 Frequently Asked Questions
Question: What software is included with the PCIe-6374?
Answer: The PCIe-6374 comes with DAQExpress™ companion software and NI‑DAQmx driver.
Question: How many counters come with the NI PCIe-6374 device?
Answer: The NI PCIe-6374 device comes with four 32-bit counters.
Question: What input would I use to receive an external pulse for the PCIe-6374?
Answer: If you want to receive an external pulse while using the PCIe-6374, as long as the external pulse is 5V digital logic you can wire it to any available PFI terminal.
PCIe-6374 PDF Manuals
DAQ GETTING STARTED GUIDE FOR PCI PCI EXPRESS.PDF
DAQ GETTING STARTED READ ME FIRST NI DAQMX AND DAQ DEVICE INSTALLATION GUIDE.PDF
NI 62XX 63XX PINOUT LABELS FOR THE SCB 68 NOTE TO USERS.PDF
NI 62XX 63XX PINOUT LABELS FOR THE SCB 68A NOTE TO USERS.PDF
NI PCIE 6374 LETTER OF VOLATILITY.PDF
PCIE 6374 SAFETY ENVIRONMENTAL AND REGULATORY INFORMATION.PDF
Driver Downloads for PCIe-6374
OS Compatibility:
Win XP 32-bit, Win 7 32-bit, Win 10 32-bit
