TB-2709, Noise-Reducing, SMB Terminal Block
Need an Official Quote?
National Instruments TB-2709 Terminal Block
The TB-2709 is a PXI Terminal Block. National Instruments produced the NI TB-2709 Terminal Block with the part number 779554-01. The TB-2709 is built for use with NI PXI data acquisition devices. The NI TB-2709 Terminal Block is fabricated to be used with S Series DAQ instruments. The TB-2709 is used with the PXI-6123, PXI-6122, PXI-6132, and PXI-6133 devices from the NI S Series. The NI TB-2709 Terminal Block can access the first 4 analog input channels of the PXI-6122 and PXI-6132 devices.
The TB-2709 Terminal Block is assembled with nine SMB connectors. There is also a 14-pin auxiliary I/O connector and a 68-position SCSI-II type female connector on the NI TB-2709 Terminal Block. The user must get grounded before operating the National Instruments TB-2709 Terminal Block. The TB-2709 does not need any external cables for connections because it provides direct connections to the S Series DAQ devices. However, the NI TB-2709 Terminal Block can be used with the 1 m, MFIT-Pigtail 14-conductor cable (Part Number: 194123-01). The NI TB-2709 is designed to work within voltages less than 42 Vpk or 60 VDC.
The National Instruments TB-2709 Terminal Block supports analog and digital triggering. The TB-2709 Terminal Block can be installed using a Number 1 Phillips screwdriver, which is the only accessory required for operation. The NI TB-2709 Terminal Block can be used with a random operating and non-operating vibration of 5 to 500 Hz.
TB-2709 Obsolete Status has been announced by National Instruments, but the Terminal Block will still be available for purchase and repairs by Apex Waves.
| Model | TB-2709 |
|---|---|
| Manufacturer | National Instruments |
| Part Number | 779554-01 |
| Type | Terminal Block |
| 68-position SCSI-II type Connector | 1 female |
| SMB jacks | 9 |
| 14-pin auxiliary connector | One, Molex 14-pin microfit connector |
| Compatible Devices | PXI-6123, PXI-6122, PXI-6132, and PXI-6133 |
| Dimensions | 4.2 × 3.4 × 0.8 in. |
| Weight | 5.1 oz. |
| Warranty | 2-3 Year Warranty |
| TB-2709 Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
