779471-01, Single Slot, USB-9162 CompactDAQ Chassis Designed for C Series Modules
Need an Official Quote?
National Instruments 779471-01 CompactDAQ Chassis
The 779471-01, often referred to as the USB-9162, is a versatile and highly portable single-module carrier CompactDAQ chassis from National Instruments. Designed for NI C Series modules, this cost-effective solution is ideal for stand-alone applications, prototyping sensor connections, and debugging larger systems. It is compatible with various C Series chassis, including NI CompactDAQ, CompactRIO, and R Series expansion chassis.
A green LED on this chassis shows the state of the device clearly and is located next to the USB port. In the event that the LED goes out, the gadget is either disconnected or in suspend mode. If there is a constant light, it means that the device is connected but either the module is not installed or it hasn't been initialized. It can also indicate that the system is in standby mode. A single blink indicates that the gadget is initialized and getting power; a double blink verifies that normal operation is occurring.
Physically, the 779471-01 is quite portable and simple to include into different configurations because it weighs only 101 grams (3.5 ounces) and measures 114.6 mm by 85.7 mm by 25.1 mm (4.51 inches by 3.37 inches by 0.99 inches).
Safety is important, and the 779471-01 has strong isolation capabilities. It can tolerate 1500 VAC and 3000 VAC of continuous voltage isolation across channels and from channel to earth ground, respectively, as confirmed by a 5-second dielectric withstand test. This is equivalent to Measurement Category II voltage isolation.
The 779471-01 is designed to withstand a variety of environmental circumstances. It may be stored at temperatures between -40 and 85 °C and works in the range of 0 to 60 °C. It can be stored in humidity levels ranging from 5 to 95% RH (non-condensing), and its working humidity range is 10 to 90% RH (non-condensing). The chassis complies with Pollution Degree 2 and is intended for usage at elevations up to 2000 meters.
| Part Number | 779471-01 |
|---|---|
| Model Name | USB-9162 |
| Part Type | Single-Module Carrier CompactDAQ Chassis |
| Bus Interface | USB 2.0 Hi-Speed |
| Current Consumption | 500 mA, max |
| Suspend Mode | 2.5 mA, max |
| Weight | 101 g (3.5 oz) |
| Dimensions | 114.6 mm × 85.7 mm × 25.1 mm (4.51 in. × 3.37 in. × 0.99 in.) |
| Isolation (Channel-to-channel) | Continuous: 250 VAC, Measurement Category II; Withstand: 1500 VAC, verified by a 5 s dielectric withstand test |
| Isolation (Channel-to-earth ground) | Continuous: 250 VAC, Measurement Category II; Withstand: 3000 VAC, verified by a 5 s dielectric withstand test |
