777852-01
Modular Systems > National Instruments > Frame Grabbers
Description: | 777852-01, 48 dB, RS-170 and CCIR, 15 MHz, PCI-1407 Frame Grabber |
Need an Official Quote?
Or speak to a sales representative for additional information:
National Instruments 77852-01 IMAQ Device
National Instruments part number 777852-01 is an identifying part number for the PCI-1407 a Monochrome IMAQ Device with 1 Video Input and 15 MHz Frequency Response. This part is designed for PCI chassis. It supports CCIR and RS-170 video standards and offers real-time frame acquisition with direct transfer to system memory. It device supports progressive scan formats and is equipped with an 8-bit analog-to-digital converter (ADC) to process video signals and convert them into digital form.
The 777852-01 delivers high accuracy, making it an excellent choice for scientific and industrial settings. This model supports one video source and one external I/O, serving as a stand-alone device. Both the video source and external device can function as a digital I/O line or trigger.
With a frequency response of 15 MHz (-3 dB) typical, the NI device supports progressive scans at rates of 25, 30, 50, and 60 frames per second. The PCI interface of this device features a 32-bit data path and operates exclusively at a voltage of 5 V. It is designed as a 32-bit half-size card, offering compatibility with systems requiring this form factor. Parity generation/checking and error reporting are supported functionalities, ensuring data integrity.
The target decode speed is classified as medium, operating at 1 clock speed for efficient processing. This user-friendly device offers easy configuration, enabling swift initiation of image acquisition using NI-IMAQ. With the PCI 1407 driver and NI-IMAQ, users can promptly launch applications without the need for programming or configuring the device at the register level. Additionally, the device can be programmed using popular application development environments such as LabVIEW, LabWindows/CVI, or Visual Basic.
Part Number | 777852-01 |
---|---|
Model Range | PCI-1407 |
Part Type | Frame Grabber |
Frequency Response | 15 MHz (-3 dB) typical |
Progressive Scan | 25, 30, 50, 60 frames/s |
Formats Supported | RS-170 and CCIR |
Video Inputs | 1 |
Input Impedance | 75 Ω (±1%), 1 Ω (±5%) |
Sampling Rate | 11.7 to 31 MHz |
Signal-to-ratio | 48 dB typical |
